If you are moving manure at any kind of scale, you have probably already hit the wall with tanker hauling. The hauls take forever. The loaded tanks compact the soil. Fuel adds up. Field windows close before you are done. A manure dragline system solves most of that by changing the fundamental problem. Instead of hauling manure to the field, you pump it there.
This guide walks through what a dragline system is, the components that make it work, when it beats a tanker, and when a tanker is still the right call.
A manure dragline system is a pumped manure application setup. You start with liquid manure in a storage pit, lagoon, or tank. A high-volume pump pushes that manure through a flexible hose, called a drag hose, that runs from the storage point all the way to the implement applying it on the field. The implement at the end of the hose moves with the tractor, dragging the hose behind it. That is where the name comes from.
The point is that you never load a tanker. You pump straight from storage to field, and you can keep pumping as long as there is manure to move and a tractor pulling the implement.
A working dragline system has five core components, plus a couple of optional pieces depending on your setup.
The pump is usually engine-driven, especially on systems that need remote engine control. Smaller systems that don’t need remote control sometimes use PTO pumps off a tractor. Sizing depends on how much volume you need to move per hour and how far you are pumping. Distance and elevation both add resistance, so larger systems use either bigger pumps or booster pumps in line.
The mainline is the lay-flat hose that runs from the storage to the field edge. It comes in 660-foot sections and connects with lay-flat hose couplings. You roll it out at the start of the season and roll it back up when you are done.
The drag hose is what actually trails the implement across the field. It is a heavier, more abrasion-resistant hose than the mainline because it gets dragged through soil and crop residue all day. Common sizes range from 4 inches to 7 inches in diameter.
The reel is how you handle the drag hose at the headlands and between fields. A good hose reel pays out the drag hose as the tractor moves into the field and reels it back when you are done. Hoover Ag makes a 66HR Hose Reel and a Skid Loader Reel for different setups.
This is what actually puts the manure on or in the ground. Options include surface applicators, dribble bars, and injection toolbars. Surface applicators lay manure on top of the ground. Dribble bars stripe it in lines close to the surface, which cuts down on odor and ammonia loss. Injection toolbars cut into the soil and place the manure below the surface, which is the most agronomically efficient option and the gentlest on the air.
When you are working a big field, you need to physically reposition the drag hose between passes. A hose mover, sometimes called a reel mover, picks up and shifts the hose so it is not dragging across already-applied ground or running over the tractor path. Hoover Ag makes a 10-foot 3-point hose mover for this.
Larger operations sometimes lay permanent or semi-permanent mainline underground or along field edges, with risers and hydrant valves that the drag hose connects to on application day. This cuts setup time on each application but adds infrastructure cost up front.
Here is the typical sequence for a day of dragline application.
You set up the mainline from the storage pit to the field. The pump goes at the storage end. You connect the drag hose to the mainline at the field edge, and the implement to the drag hose. Once the system is pressurized, the tractor pulls the implement and drag hose into the field. Manure flows continuously from storage, through the mainline, into the drag hose, and out the implement.
When the tractor reaches the end of a pass, it turns and pulls the hose along with it. The hose mover, if you are using one, repositions the hose so it does not drag across freshly applied ground. The tractor pulls back across the field on the next pass, and you keep going until the field is done or the storage is empty.
A well-set-up dragline can apply manure at rates of 1,500 to 3,000 gallons per minute or more, depending on the pump and the implement. That is an order of magnitude more throughput than a tanker fleet can deliver, with one operator on the tractor and one watching the pump.
Here is how the two approaches compare on the dimensions that actually matter.
A dragline system delivers continuous flow. A tanker fleet is gated by load and travel time. On a large field, a dragline typically applies manure two to four times faster than even a coordinated tanker operation.
Loaded manure tankers can weigh 30 tons or more. That is brutal on wet or soft soils, especially in spring and fall when application windows open. A dragline system has only the tractor and the implement on the field. No tanker weight, much less compaction. For operations on lighter soils or those that have invested in soil health, this alone is often enough to justify the switch.
Tankers can go almost anywhere a truck can drive. Draglines are limited by mainline length and by the practical limit of how much pressure you can push through it. Most dragline setups work well within a one to two mile radius of storage. Beyond that, tankers or transfer pumping start to make more sense.
A full dragline setup (pump, mainline, drag hose, reel, implement) is a significant up-front investment, easily into six figures depending on the scale. Tankers are also expensive but spread across multiple smaller units. Where dragline wins is labor. You can apply more acres with fewer people, which matters more every year as ag labor gets tighter.
Tankers need road access to the field and enough headland room to turn. Draglines can reach fields that are awkward for tankers, including fields without direct road access, since you only need a path for the drag hose and tractor. On the other hand, draglines struggle with fields broken up by ditches, fences, or terrain that the mainline cannot easily cross.
This is where dragline really shines. Tight application windows (a few good days between rains in spring, or a narrow harvest-to-planting window in fall) reward systems that can move a lot of manure in a short time. A dragline crew that knows what it is doing can cover hundreds of acres in a day.
Five situations where dragline is almost always the right call.
You are applying more than three or four million gallons a year from a consistent storage source. At that volume, the labor and time savings pay back the investment quickly.
You are applying on soils where compaction is a real problem. Cover crop fields, no-till operations, organic soils, and fields with high water tables all benefit from getting tankers off the field.
You have tight application windows. If you are trying to inject manure between corn silage harvest and the freeze, or between thaw and corn planting, throughput is everything.
You are applying long distances from storage but within practical mainline range. The combined cost of fuel, tanker time, and labor on long hauls usually loses to a pumped system.
You are doing a lot of injection. Injection requires more horsepower at the implement and slower ground speeds. Dragline’s continuous-flow advantage compounds when application speed is slower.
Do not get talked into a dragline if the math does not actually work for your operation.
Smaller operations applying less than a million gallons a year usually cannot justify the dragline investment. A well-managed tanker handles that volume fine.
Scattered fields at varying distances make dragline setup time prohibitive. If your storage serves fields in five different directions, you spend more time rolling hose than applying manure.
Highly variable manure sources (multiple lagoons, hauling in custom-source manure) work better with tankers because you can adjust on the fly.
Operations without consistent application schedules, or those that hire custom applicators, may find tankers more flexible. Custom dragline applicators exist, but they are not everywhere yet.
Three questions to start with.
Total volume drives pump and hose sizing. Application window drives how fast you need to move that volume.
This determines mainline length and pump pressure requirements. Multiple storage points or distant fields may need transfer pumping or multiple mainline runs.
The application method shapes the rest of the system. Injection draws more horsepower at the implement and benefits from larger drag hose. Surface application can run on a lighter setup.
If you are new to dragline, the cleanest path is to talk to a custom applicator who already runs the system in your area. Most are happy to demo on a real field. You learn fast what works and what does not. If you are ready to spec a system, Hoover Ag’s manure equipment lineup includes the injection toolbars, hose reels, and hose movers that build out the application end of a dragline.
A complete dragline system (pump, mainline, drag hose, reel, application implement) typically runs from $200,000 to over $500,000 depending on size, hose footage, and implement choice. Custom application by the gallon often makes sense if you are testing the approach before investing.
Most production dragline systems run between 1,500 and 3,000 gallons per minute. Larger setups with bigger pumps and 7-inch drag hose can move 4,000 gpm or more.
For a 24-foot injection toolbar with a 7-inch drag hose, you typically need 250 to 350 horsepower depending on soil conditions and ground speed.
Practical range is usually one to two miles from storage, though longer runs with booster pumps are possible. Friction losses in the hose, elevation changes, and pump capacity all matter.
Yes. Dragline systems pair with injection toolbars to place manure below the soil surface in a single pass. This is the most agronomically efficient application method for liquid manure and the gentlest on air quality.
The terms are often used interchangeably. Both describe pumped manure systems that use a flexible hose dragged behind the application implement. “Dragline” usually refers to the overall system. “Drag hose” usually refers to the specific hose at the application end.
For operations moving real manure volume, draglines change the math on application. You trade up-front cost and setup time for higher throughput, lower compaction, and tighter application windows. Whether it is the right move depends on your acreage, your storage, your soils, and your application strategy.
